Ceramic Discharge Hoses

Features

1. High wear resistance
2. Higher abrasion and corrosion resistant
3. Accept custom made
4. reduce the internal cost.

If you have any questions or concerns about our products, please feel free to contact us

Specification Packing Testing Inner Material Video

-Specification-

DN(mm)	Flange OD (mm)	Flange thickness (mm)	P.C.D.(mm)	No.of Hole	Hole die. (mm)	Length (mm)	Wall thickness (mm)
250±5	400±3	22±2	350±1	12	22±1	1000-3000	55-58

NOTE: The specifications are for reference, the Ceramic Discharge Hoses can be customized according to the client’s requests.

Good quality high wear-resistant

In the newly developed ceramic discharge hose, ceramic tips are used to eliminate a disadvantage in conventional ceramic hoses.

It owns higher abrasion resistance while maintaining flexibility. The standard producible ceramic hose is limited to 10 m in length and 30 to 300 mm in hose diameter.

Ceramic hose has a circular disk-shaped ceramic tip as compared with the conventional ball-shaped ceramic tip that shows several times higher abrasion resistance.
