DIMENSIONS
|
Length overall
|
Approx.26m
|
|
Length over pontoons
|
17.0m
|
|
|
Breadth
|
5.8m
|
|
|
Depth
|
1.5m
|
|
|
Inner Dia. of suction/discharging pipe
|
325mm/300mm
|
|
|
Max. dredging depth
|
10.0m
|
-Our Advantages-
1. Rich Experience in using of Dredger and Dredging Operation
2. International Shipbuilding Standard and Modern Engineering Technology
3. One-stop Services for the whole life-cycle of dredger products
|
DIMENSIONS
|
Length overall
|
Approx.26m
|
|
Length over pontoons
|
17.0m
|
|
|
Breadth
|
5.8m
|
|
|
Depth
|
1.5m
|
|
|
Inner Dia. of suction/discharging pipe
|
325mm/300mm
|
|
|
Max. dredging depth
|
10.0m
|
|
|
DREDGE PUMP
|
Inner Dia.of inlet/outlet
|
300mm/250mm
|
|
Shaft power
|
360kw
|
|
|
DIESEL ENGINE INSTALATION
|
Manufacturer
|
Weichai or Cummins
|
|
Main Engine Continuous service rating
|
Approx.456kw
|
|
|
Auxiliary Engine
|
–
|
|
|
Total specific fuel consumption
|
Approx.76.8L/h
|
|
|
CUTTER
|
Type
|
5 blade with 30 teeth
|
|
Diameter
|
1.0m
|
|
|
Power at shaft
|
60kw
|
|
|
Maximum speed
|
30rpm
|
|
|
WINCHES
|
Ladder hoisting winch
|
1 set 4T
|
|
Swing winch
|
2 sets 4T
|
|
|
Anchoring winch (optional)
|
2 sets 2T
|
|
|
SPUDS
|
Diameter
|
377mm
|
|
Length
|
14m
|
|
|
Hoisting cylinder
|
2.0m
|
|
|
Spud carriage range (optional)
|
2.5m
|
